40X60m Large Exhibition Marquee Tent Hall for Trade Show

_0000s_0004_背景 副本 7

Product Description

40X60m Large Exhibition Marquee Tent Hall for Trade Show

Large tent hall very hot sale for exhibition for trade show

The clear span of the Huge Hall tent is 40m, 50m, 60m and the main profile size is 400X120X5mm. This tent is a modular structure that can be increased or decreased in bay distance of 5m according to the clients’ requirements. The main frameworks (upright support and roof beam) are manufactured with high impact extruded anodized aluminum (6061/T6). The PVC covers use PVC-coated polyester textile and flame retardance which is based on the European standard DIN 4102b1, M2.

There are also many different styles sand shapes like square, hexagonal, octagonal, decagonal, dodecagonal, and double decker. All clear span big ten structures are available with a complete range of accessories. These accessories include sidewalls with clear windows, ground anchors, weight plate, lining, glass wall system, and ABS hard wall system.

1. Materials:

1.1 Frame struss: Hard pressed extruded aluminium 6061 /T6(15HW) which can last 15 to 25 years.

1.2 Fabric cover: High quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.

1.3 Connector: Strong hot-DIP galvanized steel

2. Features & Specification:

2.1 Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
2.2 Wind load: Max. 100km/h (can be reinforced)
2.3 Snow load: 75kg/sqm (snow can’t stay if use big degree roof pitch design)
2.4 Easy to be assembled and dismantled, movable
2.5 No pole inside, 100% interior space is available
2.6 Sizes can be customized

3. Optional accessories for 500 People Marquee Wedding Tent:

3.1 covers: Colourful cover, transparent cover, inflatable roof cover

3.2 windows: Dome or square clear PVC windows, mesh window, glass window for glass wall

3.3 wooden flooring system: VIP cassette flooring, simple cassette flooring

3.4 doors: Double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)

3.6 wall: Soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall

3.7 fixing methods: Ground anchors, weight plate, expandable bolts

3.8 rain gutters (inner roof beam rain gutter or rain gutter between two similar tents)

3.9 other optional items: Table, chair, lighting, AC, carpet, installation tools etc.

4. Application of Wedding Tent:
Widely used as wedding marquee tent, event tent, party tent, festival tent, racing tent, sports tent, exhibition tent, tradeshow tent, warehouse tent, storage tent, outdoor activity marquee tent,
And tent hire business, event design business, church tent, Hajj tent, Arabian Ramadan tent, etc…

5. For more available tent models, pls visit Liri website: http://www.liri-tents.com or http://www.liri-structures.com

To download our product catalog: http://www.liri-tents.com/en/download/index_272. HTML

Tent Roof Type Span Width Bay Distance Eave Height
“A” Shape 3m~60m 3m/5m 2.6m/3m/3.3m/3.88m/4.2m/5m/5.2m
Domelike 3m~40m 3m/5m 2.6m/3m/3.23m/3.88m/3.92m
High Peak  3m~10m 3m/4m/5m/6m/8m/10m 2.5m/2.6m
Curve Shape 15m~40m 5m 3.87m/3.89m
Polygon 10m~60m 5m 4m
Cube Structure 10m~30m 5m 5m
