Outdoor Marquee Tent With Digital Printing For Event
Liri BT Series specifications:
| Type | Span Width | Bay Distance | Eave Height | Ridge Height | Main Profile |
| BT | 10m/32.8′ | 5m/16.4′ | 3.88m | 5.53m | 204x120x4mm(4-channel) |
| BT | 12m/39.4′ | 5m/16.4′ | 3.88m | 5.83m | 204x120x4mm(4-channel) |
| BT | 15m/49.2′ | 5m/16.4′ | 3.88m | 6.3m | 204x120x4mm(4-channel) |
| BT | 20m/65.6′ | 5m/16.4′ | 3.88m | 7.1m | 204x120x4mm(4-channel) |
| BT | 21m/68.9′ | 5m/16.4′ | 3.88m | 7.25m | 204x120x4mm(4-channel) |
| BT | 25m/82′ | 5m/16.4′ | 3.88m | 7.88m | 204x120x4mm(4-channel) |
| The length can be extended by 5m bay such as 15m,20m,30m,40m…Customized size is available. | |||||
- Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
- Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
- Connector: strong hot-dip galvanized steel
- Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
- Wind load: max. 100km/h (can be reinforced)
- Snow load: 75kg/sqm (snow can’t stay if use big degree roof pitch design)
- Easy to be assembled and dismantled, movable.
- No pole inside, 100% available interior space.
>> Applications of Our Tents
- Widely used for Weddings, Events, Parties, Celebrations,Sports,Trade show, Warehouse, etc.
>> Fixing Methods of outdoor marquee tent
>> Accessories of outdoor marquee tent
- Covers: colourful cover, transparent cover, inflatable roof cover
- Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
- Wooden Flooring System: VIP cassette flooring, simple cassette flooring
- Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
- Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
- Fixing Methods: ground anchors, weight plate, expandable bolts
- Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
- Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
