Outdoor Marquee Tent With Digital Printing For Event

Liri BT Series specifications:

Type	Span Width	Bay Distance	Eave Height	Ridge Height	Main Profile
BT	10m/32.8′	5m/16.4′	3.88m	5.53m	204x120x4mm(4-channel)
BT	12m/39.4′	5m/16.4′	3.88m	5.83m	204x120x4mm(4-channel)
BT	15m/49.2′	5m/16.4′	3.88m	6.3m	204x120x4mm(4-channel)
BT	20m/65.6′	5m/16.4′	3.88m	7.1m	204x120x4mm(4-channel)
BT	21m/68.9′	5m/16.4′	3.88m	7.25m	204x120x4mm(4-channel)
BT	25m/82′	5m/16.4′	3.88m	7.88m	204x120x4mm(4-channel)
The length can be extended by 5m bay such as 15m,20m,30m,40m…Customized size is available.

Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
Wind load: max. 100km/h (can be reinforced)
Snow load: 75kg/sqm (snow can’t stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.

>> Applications of Our Tents

Widely used for Weddings, Events, Parties, Celebrations,Sports,Trade show, Warehouse, etc.

Covers: colourful cover, transparent cover, inflatable roof cover
Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
Wooden Flooring System: VIP cassette flooring, simple cassette flooring
Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
Fixing Methods: ground anchors, weight plate, expandable bolts
Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
