500 People New Design Large Hajj Tent in Arab


Product Description

1. Application:

The hajj tent can be widely used as the hajj events, ramandan, pray, church, exhibition, , festivals celebrations, cafe shop, restaurants, corporate events, or other events, etc

2. Specification for the Hajj (BT series):

For details, pls refer to below chart:

Main frame profile size for BT series: 204X120X4mm
Wind load: 100km/h
Minimum tent length: In order to reach the designed wind load and make sure the tent is safety, pls set up the tent with the required minimum tent length.

3. Optional Accessories:
Ground anchor, anchor puller, weight plate, glass door, fire door, glass wall, ABS hard wall, lining, flooring system, clear PVC windows, ramp, transport rack etc

4. Materials:

Fabric: Double PVC coated polyester fabric, 750-900g/sq. M, water proof, UV resistance, fire retardant according to standard NFPA701, CFM & DIN4102 B1/M2
Frame: Hard pressed extruded aluminum 6061/T6, anodized surface finishing.
Connections: Hot-DIP galvanized

5. Color available: White, red, yellow, blue, green, black, grey, transparent etc

6. Products certificate:

Fabric: Test reports for the fire retardant, standards: NFPA701, CFM & DIN4102 B1/M2
Structure safety: Certificates by the registered engineers in the U. S. A & Australia.

If the customers need above certificates copy, pls feel free to contact with Liri Tent Technology. We will not show them on the website to avoid copys.

Dimension Clear Span Eave Height Ridge Height Bay Distance
BT10 10m 4m 5.53m 5m
BT 12 12m 4m 5.83m 5m
BT 15 15m 4m 6.3m 5m
BT 18 18m 4m 7.06m 5m
BT20 20m 4m 7.1m 5m
BT21 21m 4m 7.25m 5m
BT25 25m 4m 7.88m 5m
Length No limitation
Main Structure Profile 204*120*4mm
